Three way rotatable 180 degree Satin Crhoem adjustable invisible
hinge
Item No.: BG001
Name: Three way rotatable 180 degree Satin Crhoem adjustable invisible
hinge
3D Adjustable Invisible Hinge Details:
| Type | door and window & table soss type concealed hinge |
| Model number | BG001 |
| Size | 30x110mm |
| Intermediate gap | 16mm |
| opening angle | 180 degree |
| min. door thickness | 40mm |
| max. door weight | 60kg/3 pcs |
| Origin | Jiangmen, CHINA |
| material | zinc alloy, stainless steel #304 |
| connector | SS 304 |
| screws | stainless steel #304 |
| coating | satin nickel, satin chrome, pearl nickel, pearl chrome, gold
plated, antique bronze and antique copper or as your requirement |
Product features
- completely concealed hinge system
- for timber, steel or aluminium frames
- for unrebated residential and heavy-duty doors
- maintenance-free slide bearings
- with comfortable 3D adjustment (side +/- 3,0 mm, height +/- 3,0 mm,
compression +/- 1,0 mm)
- sideways closed hinge body for a homogeneous mortise appearance
Advantages:
- concealed hinge
- Brand-name Parts
- Experienced Staff
- Product Features
- High reputation
- Prompt Delivery
- Small Orders Accepted
- Guarantee/Warranty
Design meets function. SG enables the optimal integration of
unrebated doors in straight line and surface flush room structures.
The completely concealed hinge system SG accepts load capacities of
up to 300 kg, enables an opening angle of 180 degrees and can be
used on timber, steel and aluminium frames.
The three-dimensional adjustability and maintenance-free slide
bearing technology of SG are used for high-quality residential
doors and functional heavy-duty doors.
Queations customers may ask:
1, Samples' free or charged including the express cost?
Samples' cost less than USD 50.00 will not be charged, express cost
on customer's side.
2, Factory area and number of employees?
5000 ㎡&200 workers
3, Delivery time for regular orders?
We always keep s small amount of stock(around 1000 pcs for each
sizes), and for mass orders, certainly finish from 15 days up to 30
days.
4, Your capacity for one month?
Up to 500,000 pcs accoding to different sizes.
5, Your annual sales value?
In 2017, exceed 6 million dollars.
6, How will you treat on after-sale quality problems?
If responsibility confirmed on our side, we will make full
compensation for free including shipping charge.
